Specications
Work Height* 71 ft 21.6 m
Platform Height 65 ft 19.8 m
Maximum Drive Height Full Height
Maximum Outreach 47 ft 14.3 m
Turntable Swing Continuous
Jib Range Of Motion 135°
Platform Rotation 180° (90° Each Side)
Machine Weight** (Unloaded) 21,800 lb 9,890 kg
Lift Capacity
Up To Serial #14800199 500 lb 227 kg
From Serial #14800200 600 lb 272 kg
Maximum Occupants 2
Stowed Height 102 in 2.59 m
Overall Length 32 ft 9.8 m
Overall Width 98 in 2.49 m
Tailswing 50 in 1.27 m
Wheel Base 101 in 2.56 m
Platform
Details
Width 90 in 2.3 m
Depth 40 in 1 m
Entry
1 End Swing Gate
2 Slide Bar Entries
Turning Radius, Inside 6 ft 6 in 2 m
Ground Clearance 15 in 38 cm
Lift Speed 60 sec
Extend Speed 30 sec
Jib Lift Speed 15 sec
Drive Speed
(Proportional)
Stowed 0-4.0 mph 0-6.4 km/h
Raised or Extended 0-0.5 mph 0-0.8 km/h
Gradeability
Stowed, Downhill 45%/24.2°
Stowed, Uphill 45%/24.2°
Breakover Angle 40%/22°
Axle Oscillation 10° (5° Each Side)
Maximum Allowable Operating Wind
Speed
28 mph
12.5 m/sec
(45 km/h)
Engine Kubota V1505-T 44HP
Fuel Type Diesel
Fuel Capacity 32 gal 120 liter
Hydraulic Fluid Capacity 40 gal 150 liter
Sound Pressure At
Workstation
80 dB(A)
Maximum Vibration
Does not exceed 8.2 ft/sec
2
(2.5 m/sec
2
) at operator’s position
Sound Power Level 86 dB @ 1m
Ambient Operating Range
-20° F min
120° F max
-29° C min
49° C max
Ground Pressure/Wheel
(Maximum)
69 psi 4.86 kg/cm
2
Wheel Lug Nut Torque 150 lb-ft 203 Nm Maximum Wheel Load 6,060 lb 2,750 kg
Meets requirements of ANSI A92.20-2020 and CSA B354.6-2019.
Allowable ambient temperature range: -20° F to 120° F (-29° C to 49°C).
Consult with MEC for operation outside of this range.
*Working Height adds 6 feet (2 m) to platform height.
**Weight may increase with certain options.
