Page 14 65-J Diesel - Operator’s Manual
September 2022Section 5 - Controls & Components
Base Controls
ART_5660
17
18
16
13 12
11 10
1415
32 4 51
9
7
8
6
ALWAYS check over, under and around the machine for personnel,
structures and obstructions before activating any control function and
continue to watch for hazards while operating the machine.
Control Description
1 Hour Meter Indicates total elapsed time of machine operation.
2 Selector Switch
Platform Select to operate from the platform control panel.
Base Select to operate from the base control panel.
O Select to stop operation from either control panel.
3 Start/Stop Switch Push switch up to start engine. Push switch down to stop engine.
4 Glow Plug Light
The light will turn on when the Kubota ECU determines it necessary to activate glow plugs
before starting the engine.
