Page 43 92RT Scissor Lifts - Operator’s Manual
July 2020Section 13 - Troubleshooting
Serial Plate Location
The serial plate is attached to the machine
at the time of manufacture. Important
information about the machine is recorded
on the serial plate.
Serial Plate Description
XX/XX
MONTH
YEAR
MFG DATE
ART_2377
5492 RT
Max. platform height
in FEET
Machine width
in INCHES
Rough
Terrain
MODEL NUMBER
ART_3028
MFG DATE. Month / Year of manufacture
MODEL NUMBER. Identifies the machine.
SERIAL NUMBER. Identifies a machine with reference to its original owner. Refer to
the number when requesting information or ordering parts.
MAX. WIND SPEED. The maximum safe wind speed at which the machine can be
elevated.
MAX. PLATFORM CAPACITY
INCLUDING PERSONS.
The maximum safe load (persons + equipment) which
can be evenly distributed on the platform at any
elevation.
MAX. ALLOWABLE
MANUAL FORCE.
The maximum safe force that the occupant can exert laterally
on an object outside the platform.
MAX. PLATFORM
HEIGHT.
The maximum attainable height measured from level ground
surface to platform floor.
MAX. DRIVE
HEIGHT.
The maximum safe platform height at which the machine can be driven.
MAX. LOAD
PER WHEEL.
The maximum safe weight applied to each wheel. Calculated with all
available options installed. Fw = 30% (Wm + Wc + Wopt)
MAX. GROUND
PRESSURE
PER WHEEL.
The amount of pressure exerted on the surface at each wheel.
Calculated with all available options installed. Pmax = 30% (Wm +
Wc + Wopt) / Contact Area
STANDARD MACHINE WEIGHT. The weight of the machine with no options.
OPTIONAL EQUIPMENT ADDS TO
STANDARD MACHINE WEIGHT.
The weight of installed optional equipment.
