9
EN
WARNING: During the tightening
and removing operations, the user must
pay particular attention to avoiding
injury from inserts with sharp points
and cutting edges.
8
10
9
7
Unscrew the front cone of the handpiece;
NOTE - USE OF THE HANDPIECE WITH
LIGHT: on the cone with LED light the
metal ring cannot be separated from the
cone in plastic;
If the bone grafting kit has been used,
disconnect the tube-to-tube connector
from the peristaltic pump tube and from
the tube of the bone grafting kit;
If present, unscrew the insert from the
handpiece by using the torque wrench;
Remove the protective foil from the
keyboard, if present.
03 DISASSEMBLY
