List of Spare Parts

Confidential Information of MEDCAPTAIN MEDICAL TECHNOLOGY CO., LTD. 71/ 82

Door

assembly

1401-00038-01

HP-30 door

spindle

Section 8.7

Note: The list of spare parts is updated as requested based on product changes and maintenance at regular

intervals.
