Pad input jacks
Connect with pads, cymbals, hi-hat control,
kick trigger.
Line output jacks (R, L/mono)
made up of right channel output and left
channel output which is also used as mono
line output.
Aux.in jack
Connect with external sound source.
Power supply jack ( DC in 9V)
Connect an AC adaptor to this jack.
Power switch
Turn the power on/off.
MIDI IN and OUT connector
Connect with external sound module.
Rear Panel
Side Panel
USB Port
Connect to computer.
Phones jack
Connect a pair of stereo headphones to this jack.
(Connect the headphones will not mute the output jacks.)
5
