9
Connections
Sustain Jack
USB Jack
An optional footswitch can be plugged into the
SUSTAIN jack for sustain control.
The footswitch functions like the damper pedal of a
piano. Press for sustain, release for normal sound.
Connect PC or other USB host devices that support
USB Audio.
For devices with USB cable, after the driver is installed
and initialization is finished, you can choose USB Audio
Device in the device menu of the software to transfer
midi data.
1.
1.
2.
2.
To avoid damages, turn the power switches of
this keyboard and all related devices OFF if you
want to plug in or unplug between this instru-
ment with all related devices.
WARNING
PHONES SUSTAINUSB
12V
