Setup
Rear Panel
1. MIX MODE SECTIONS
2. ALBUM
3. TOUCH
4. SUSTAIN
5. MIX CONTROL
6. SOUND/STYLE/DEMO/SONG/MIX
7. MEASURE
8. BEAT
9. TEMPO
10. MEMORY/QUICK SETTING
11. LAYER/SPLIT/HARMONY/ARP./DSP
12. LEFT/RIGHT HAND LESSON MODE
13. NUMBER MUSICAL NOTATION
14. FINGERED/FULL RANGE/FADE/A/B
15. CHORD
16. AUDIO RECORDING
17. RECORDING FILE
18. TREBLE CLEF
19. BASS CLEF
20. MIX MODE TRACKS
21. USB
22. SD CARD
23. CHARACTER
39. SD Card port: For inserting an SD Card.
40. USB Port: For connecting to a computer.
41. SUSTAIN Jack: For connecting a sustain pedal.
42. PHONES Jack: For connecting a pair of
headphones.
43. Aux IN Jack: For connecting external audio
source, such as an MP3 or CD player.
44. MIC IN Jack: For connecting a microphone.
45. Power Jack: For connecting the specified
power adapter.
06
LCD
39 40 41 42
43 44 45
2
5
4
3
6
7
8 9
12
14
16
15
17
18
19
20 21 22
23
13
1
10
11
