DLRO10HD and DLRO10HDX
27
Specifications
Power Lead
If the power lead supplied is not suitable for your Mains Power connection, do not use an adaptor. Always use a
power lead installed with the correct plug. The instrument has a two-pin IEC60320 Mains Power socket.
Most power leads are made with three-core cable, so the ground connection will not be used.
Power Lead Connection Table
Connection K / International USA
Earth / Ground Yellow / Green Green
Neutral Blue White
Live (Line) Brown Black
If a fused plug is used, make sure that it is installed with a 3 A fuse.
The instrument can be powered from 100 - 240 V 50 / 60 Hz 90 VA.
