www.megger.com
35
Specification
MAINS SUPPLY TEST
Frequency measurement range 50 Hz
Test voltage 40 to 300 V ac
Accuracy ± 3% ± 3 digits
Resolution 0.1 V ac
Display range 40 to 300 V ac
CIRCUIT TEST
(Carried out automatically, not available to user)
Test voltage 5 V
Test frequency Nominal Mains 50 Hz
Test current < 100 mA short circuit
SAFETY
Instrument designed to IEC 61010-1: 2010
Test leads designed to IEC 61010-031: 2008
300 volts to Earth Category II
Mains fuse protection to 250 volts rms ac
EMC
Design to meet IEC 61326-1: 2012 and IEC 61326-2-2: 2005.
FUSE
(user replaceable)
UK variants has mains plug fuse
One F 100 mA 250 V 5 x 20 mm HBC fuse.
ENVIRONMENTAL
Operating temperature range 0°C to +40°C
Storage temperature range -20°C to +60°C
Humidity 90%RH @ +10°C +30°C
75%RH @ +30°C to +40°C
Maximum altitude 2,000m to full safety spec.
IP rating IP40 (with front cover closed)
MECHANICAL
BATTERIES
Battery life > 30 hrs 20sec:2min Test:Standby ratio
Battery type Supply voltage
12 Vdc (Alkaline AA LR6)
9.6 Vdc (NiMH AA LR6)
WEIGHT
PAT120 (instrument only): 1150 g (40.4 oz)
Shipping weight: 2370g (83.6 oz)
PAT150 (instrument only): 1300 g (45.8 oz)
Shipping weight: 2795g (98.6 oz)
PAT150R (instrument only): 1300 g (45.8 oz)
Shipping weight: 2975g (104.9 oz)
DIMENSIONS
Dimensions (instrument and case) 203 mm (L) x 148 mm (W) x 78 mm (H)
(8 x 5.7 x 3.2 inches)
Dimensions (instrument and packaging) 456 mm (L) x 178 mm (W) x 89 mm (H)
(18 x 7.1 x 3.5 inches)
