Step Action
3 The inner conductor of the HV connection cable must be connected by
means of suitable connection accessories to either the phase or the
screen of the cable under test.
When working in sheath test or sheath pinpointing mode, the cable
screen must not be connected to earth on both ends of the cable.
Make also sure that there is no indirect contact to earth, e.g. through
joints.
4 The screen of the HV connection cable has to be connected to an earth
bar close to the cable termination (system earth).
5
Plug the supplied power cable into the power connection of the system
and connect it to a mains socket.
3.2 Switching On the System
Switching on
Before it is switched on with the on/off button , the device is in the 'Out of service' state.
Once the button is pressed, the system is in the 'Ready for operation' state. The
operational readiness is indicated by the lit button. The controls are activated and after a
short booting phase the start menu appears.
The high voltage source is switched off and the high voltage output is earthed via a
discharge resistor.
After the booting process, the start menu appears, from which a test with the settings of
the previous test can be immediately started via the Start button (see section 4.4).
If instead you need to change the system or test settings in preparation for the upcoming
test, the Menu button takes you to the settings menu (see section 4.3).
10.10.2008 / 14:06:19
Mode:
VLF Sinus
30min
Menu
Start
5.0kV
To Next Page
