Megmeet MV600L Series User Manual

26
function
selection
8: Frequency upper limit (FHL)
9: Frequency lower limit (FLL)
10: Drive running at zero-speed
15: Drive ready for running (RDY)
16: Drive fault
18: Brake control signal
19: Limiting torque
21: Zero servo completed
34: Drive FWD/REV indication
terminal
41: Safety terminal signal output
(sg)
P09.20
Relay
BRA/BRC
output
function
selection
BRA/BRC
function
selection
1 18 √ √ ×
P09.21
Output
terminal
enabled
status
setting
Output
terminal
enabled
status
Binary setting:
0: Enabled upon connection
1: Enabled upon disconnection
Unit place of LED:
BIT0~BIT3: Y1, Y2, TATBTC,
BRABRC
1 0 × √ ○
P09.22
Relay
TATBTC,
BRABRC
output
delay
Relay
TATBTC,
BRABRC
output delay
0.1~10.0s 0.1s 0.1 × √ ○
P09.23
Frequenc
y arrival
(FAR)
detection
width
Frequency
arrival
detection
width
0.00~3000.00Hz 0.01Hz 2.50Hz × √ ○
P09.24
FDT 1
level
upper limit
FDT 1 level
upper limit
P09.24~P02.16 0.01Hz 50.00Hz × √ ○
P09.25
FDT 1
level
lower limit
FDT 1 level
lower limit
0.00~P09.23 0.01Hz 49.00Hz × √ ○
P09.26
FDT 2
level
upper limit
FDT 2 level
upper limit
P09.26~P09.24 0.01Hz 25.00Hz × √ ○
P09.27
FDT 2
level
lower limit
FDT 2 level
lower limit
0.00~P02.16 0.01Hz 24.00Hz × √ ○
P09.28
DO
terminal
output
Digital output
0: No function
1: Output frequency
2: Set frequency (0~Maximum
output frequency)
3: Output current I
ei
(0~2 * I
ei
)
4: Output current I
em
(0~2 * I
em
)
1 2 √ √ ○
