Megmeet MV600L Series User Manual

27
5: Output torque (0~3 * T
em
)
6: Output torque current
(0~3*I
tem
)
7: Motor rotating speed
(0~Maximum output frequency)
8: Output voltage (0~1.5 * V
e
)
12: Output power (0~2*P
e
)
13: Electric torque limit value
(0~3T
em
)
14: Braking torque limit value
(0~3T
em
)
15: Torque offset (0~3T
em
)
16: Torque reference (0~3T
em
)
P09.33
Zero-spee
d
threshold
Zero-speed
threshold
0.0%~100.0% of maximum
frequency
1.0% 1.0% × √ ○
Group P10: Analog input/output terminal parameters
P10.00
Analog
input
properties
Analog input
properties
Unit place: AI1
0: Voltage input
1: Current input
Tens place: AI2
0: Voltage input
1: Current input
AI3 is the differential voltage input
1 00 √ √ ×
P10.01
Analog AI
function
selection
AI function
selection
Unit place of LED: AI1 function
selection
0: No function
1: Main reference frequency
setting
2: Auxiliary reference frequency
setting
3: Torque offset
4: Speed limit value 1
5: Speed limit value 2
6: Torque limit value 1
7: Torque limit value 2
8: Torque command (reference)
9: Main reference frequency
setting (unipolar)
A: Auxiliary reference frequency
setting (unipolar)
B: Motor temperature detection
C: Output voltage offset (under
V/F)
D: Output voltage (under V/F)
1 000 √ √ ×
