5.7 Status Indicators
CPU:
—————————————————————————–
R (Receiver)
green: the reference clock (e.g. build-in GPS180)
provides a valid time
red: the reference clock does not provide
a valid time
T (Time Service)
green: NTP is synchronized to the
reference clock, e.g. GPS180
red: NTP is not synchronized or
switched to the "local clock"
N (Network)
green: all monitored network interfaces
are connected ("Link up")
red: at least one of the monitored
network interfaces is faulty
A (Alarm)
off: no error
red: general error
—————————————————————————–
REC:
—————————————————————————–
Fail
red: no synchronization
Ant
red: no synchronization resp. no antenna
connected or shor t circuit on the antenna line
green: antenna connected and clock is synchronized
Nav
green: positioning complete
Init
blue: initialisation phase
green: "warmed up" - oscillator is adjusted
—————————————————————————–
Fail
Ant
Nav
Init
R
T
N
A
CPU REC
20 Date: 17th June 2020 microSync
