9 Technical Appendix
9.1 Technical Specifications GPS Receiver
Receiver: 12 - channel C/A code receiver with external antenna/converter unit
Antenna: antenna/converter unit with remote power supply
refer to chapter "Technical specifications of antenna"
Power Supply 15 V DC, continuous short circuit protection, automatic recovery
for Antenna: isolation voltage 1000 VDC, provided via antenna cable
Antenna Input: antenna circuit dc-insulated; dielectric strength: 1000V
length of cable: refer to chapter "Mounting the Antenna
Time to one minute with known receiver position and valid almanac
Sychronization: 12 minutes if invalid battery buffered memory
Pulse Outputs: eight programmable outputs (PP 1 - PP 8)
DC-insulated by optocouplers
U
CEmax
= 55 V, I
Cmax
= 50 mA, P
tot
= 150 mW, V
iso
= 5000 V
pulse delay: t
on
e.g. 20 µsec (I
C
= 10mA)
t
off
e.g. 3 µsec (I
C
= 10mA)
change of second (P_SEC, TTL level)
change of minute (P_MIN, TTL level)
Accuracy after synchronization and 20 minutes of operation
of Pulses: OCXO SQ/MQ/HQ/DHQ: better than ±50 nsec
better than ±2 µsec during the first 20 minutes of operation
Frequency
Outputs: 10 MHz, TTL level into 50 Ohm
1 MHz, TTL level
100 kHz, TTL level
Frequency
Synthesizer: 1/8 Hz up to 10 MHz
Accuracy of
Synthesizer: base accuracy depends on system accuracy
1/8 Hz to 10 kHz Phase syncron with pulse output P_SEC
10 kHz to 10 MHz frequency deviation < 0.0047 Hz
Synthesizer
Outputs: F_SYNTH: TTL level
F_SYNTH_OD: open drain
drain voltage: < 100 V
sink current to GND: < 100 mA
dissipation power at 25
◦
C:< 360 mW
F_SYNTH_SIN: sine-wave
