6.1 Antenna Cable:
Cable type
Cable (mm/in)
Attenuation at 100 MHz
(db)/100m/328ft
max. Cable lenght (m/ft)
used for receiver type
RG58/CU
5/0.2
17
300/984
GPS/GNS-UC/PZF
RG213
10,3/0.41
7
700/2297
GPS/GNS-UC
H155
5,4/0,21
9,1
70/230
GNM/GNS
H2010 Ultraflex
7,3/0,29
5,8
150/492
GNM/GNS
Further values can be found in the data sheet of the cable used.
6.2 Antenna Short-Circuit
(Only for assembly groups with front display)
In case of an antenna line short-circuit the following message appears in the display:
ANTENNA
SHORT-CIRCUIT
DISCONNECT POWER
! ! !
If this message appears the clock has to be disconnected from the mains and the defect eliminated. After that
the clock can be powered-up again. The supply voltage for the antenna/converter unit is approx. 15 V DC when
the antenna is connected.
