12 Attachment: Technical Information
12.2 Rear Panel Connectors
Name Type Signal Cable
—————————————————————————————————————————
2 x Power supply 100 V - 240V / 500 W power cord receptacle
GPS Receiver
Antenna BNC female 10 MHz / 35.4 MHz shielded coaxial line
or
combined GPS/GLONASS/Galileo/BeiDou Receiver
L1 Antenna SMA connector 1575.42 +- 10 MHz shielded coaxial line
1602-1615 MHz
IRIG Time Code (AM) BNC female 3 V
pp
into 50 Ohm shielded coaxial line
VGA 15pin D-SUB Integrated video standard
Video modes up to 1920 x 1200@60Hz (32 bpp)
16 MB video memory shielded data line
2 x USB 3.0 USB connector
1 x iLO RJ45 Management Port shielded data line
4 x LAN Port RJ45 1 GbE Adapter shielded data line
Optional
—————————————————————————————————————————
4 x LAN Ports (add.) RJ45 10/100/1000 Mbit/s shielded data line
or
2 x LAN Ports (add.) SFP Slot 10GBASE shielded coax line
Second Receiver
GPS Antenna BNC female 10 MHz / 35.4 MHz shielded coaxial line
or
combined GPS/GLONASS
L1 Antenna SMA 1575.42 +- 10 MHz shielded coaxial line
1602-1615 MHz
IRIG Time Code (AM) BNC female 3V
pp
into 50 Ohm shielded coaxial line
Information for ensuring
electromagnetic compatibility
All data and signal cables must have sufficient shield-
ing. The use of cable type S/FTP Cat5 or better is
recommended. Use of unshielded or badly shielded
cables may lead to increased emi ssion of interference
and/or reduced fault-tolerance of the device.
SyncFire 1200 Date: 31st March 2021 43
