SERVICE - UIS
1
3
2
page 18
18. Adjusting and dismantling the inner door on incubators (Ixx)
Release the screws (1), do not unscrew the screws completely, otherwise the fixing block (inside)
drops down.
Adjust the inner door (3) and tighten the screws (1) again.
Check screw (2) and tighten if necessary.
If the fixing block has dropped down, access to it is obtained by pulling out the side panel so that it can
be fitted again.
To dismantle the inner door, release the screw (2) (hold with a spanner), tilt the glass door to the front and
lift it out of the bottom hinge.
•
•
•
