Here above you can see a short description of all the pushbuttons that can be
used to configure your MyChron 3:
• General: with this pushbutton you enter the window on page 44;
• Visualization: this pushbutton allows you to set the pressure and
temperature alarms values and to set the RPM changing gear threshold
values;
• Channels: by using this option you can set how many and which kind of
sensors are installed on your vehicle;
• Logger information: this button allows the user to detect the
characteristics of the data logger connected to the PC;
• Transmit: once configured the data logger, the parameters have to be
transmitted to the instrument by clicking this button;
• Receive: if you connect to a PC a data logger of whom you do not know
the configuration, you may detect its configuration, by clicking the
Receive button, and to save it in the configuration’s database;
• Online: the Online button allows the user to make a data acquisition
simulation, in order to verify if the new configuration is correct and if it
has correctly been transmitted to the data logger;
• New / Delete / Clone: these three buttons allows the user to create a
new configuration, to delete an old one or to clone an existing one;
• Exit: this button is used to exit the “Logger manager” menu.
47
