Mendota FV46 - Page 40

85-03-01108 FV46 Page 40
Approved Vent Systems
NOT APPROVED
NOT APPROVED
V2
V1
V2
H2
V1
V2
V
V
STRAIGHT UP,
VERTICAL VENTING
APPROVED
50 FEET
MAXIMUM
APPROVEDAPPROVED
APPROVED
APPROVED
APPROVED
H2
V
APPROVED
HORIZONTAL RUN
WITH 90 DEG
ELBOW.
H2
V1
H1
H1
H1
H
H
H
H
THREE HORIZONTAL DISCHARGE
90° ELBOWS
VERTICAL RISE
TRIPLE 90° ELBOWS
VERTICAL TERMINATION
VERTICAL RISE
TRIPLE 90° ELBOWS
HORIZONTAL TERMINATION
VERTICAL RISE
DUAL 90° ELBOWS
HORIZONTAL TERMINATION
VERTICAL RISE
DUAL 90° ELBOWS
VERTICAL TERMINATION
VERTICAL RISE
HORIZONTAL TERMINATION
MINIMUM 12" VERTICAL
