Mendota FV48 - Page 41

85-03-01194 FV48 Page 41
Approved Vent Systems
NOTE: Additional venting configurations are allowed when using a power vent. Consult the power vent instructions for more
information.
ZERO VERTICAL
HORIZONTAL TERMINATION
VERTICAL RISE
HORIZONTAL TERMINATION
ZERO VERTICAL
DUAL 90° ELBOWS
VERTICAL TERMINATION
VERTICAL RISE
DUAL 90° ELBOWS
VERTICAL TERMINATION
VERTICAL RISE
DUAL 90° ELBOWS
HORIZONTAL TERMINATION
VERTICAL RISE
TRIPLE 90° ELBOWS
HORIZONTAL TERMINATION
VERTICAL RISE
TRIPLE 90° ELBOWS
VERTICAL TERMINATION
THREE HORIZONTAL DISCHARGE
90° ELBOWS
STRAIGHT UP,
VERTICAL VENTING
NOT ALLOWED
APPROVED
H
H
H
H
H1
H1
H1
V
V
V2
V1
V2
V1
V2
H2
V1
H2
V
H2
APPROVED
NOT ALLOWED
APPROVED
APPROVED
APPROVED APPROVED
40 FEET
MAXIMUM
APPROVED
NOT ALLOWED
