ENGLISH
87
DESCRIPTION
CONTROL PANEL
1. Power switch: switches power supply on and off.
2. Status light: goes on when power switch is pressed in.
3. Programme selector: turn to select wash programme.
4. Start/Reset: press to start/pause wash programme.
5. Status light Start/Reset: the light goes off in stand-by mode after wash programme has finished.
The light flashes when wash programme is in progress. The light goes on when the door panel is
opened during a wash programme, or if a wash programme is paused.
6. Warning light for salt: goes on when dishwasher salt/softener needs topping up.
7. Warning light for rinsing agent: goes on when container for rinsing agent needs topping up.
Dishwasher
1. Salt container
2. Compartment for dishwasher detegent
3. Cutlery basket
4. Filter unit
5. Container for rinsing agent
6. Rinse arms
7. Cup shelf
8. Basket
9. Outlet port
10. Inlet port
Front view
Rear view
