Overview TS790+ & TS900+ Installation Manual
2
Remote Keypads
Up to 4 remote keypads can be connected to
the control panel. Each remote keypad has two
detection circuits and a single switched -ve
output. There are four types of remote keypads
that can be used:
32 Character LCD (NETLCD)
The NETLCD remote keypad has a backlit 32
character super-twist Liquid Crystal Display (LCD)
and a backlit tactile rubber keypad. When using
the LCD Keypads the text for user codes, part
setting modes and circuit identification can be
programmed to make the operation and
programming of the system easier.
8 Character Starburst (NETSTAR)
The NETSTAR remote keypad has a backlit 8
character starburst display (LCD) and a backlit
tactile rubber keypad.
4 Character LED (NETLED)
The NETLED remote keypad has a 4 character
LED display and backlit tactile rubber keypad.
When using the LED remote keypads, text
cannot be programmed but all other system
functions are available.
Remote Arming Station (NETARM)
The Remote Arming Station only allows setting
and unsetting of the system. The unit has two
indicator LEDs, the “Power LED” and a
programmable “Function LED” (the “Function
LED” may be programmed as “Fault” or “Area
Set” etc.).
TSXNODE
The XNode provides eight programmable
detection circuits and two programmable
outputs (one switched +ve and one switched -
ve). Use the XNode to replace the TS900 Node
where necessary. (Do not use on the TS790+.)
TS900 NODE (Obsolete)
The TS900 Node provides eight programmable
detection circuits and two programmable
outputs. (Do not use on the TS790+.)
ID Node (TS900 IDNODE)
The TS900 IDNode can be used as an
alternative to the standard XNode. It provides a
single ID Detector Loop for connection to 30 ID
devices and 8 programmable outputs. Several
configuration options allow it to be used on its
own or with existing XNodes. You can also
connect two IDNodes to give a total of 40
zones. (Do not use on the TS790+.)
TS700 LEC
The Local Expansion Card (LEC) provides two
programmable detection circuits and one
programmable output.
