Merak MEP2L - Hardware and firmware version check; Auxiliary output; Telephone line signalling (SLT)

MEP2L
EMERGENCY TELEPHONE FOR LIFTS
Rev. M2.4 © Merak. All rights reserved
Command Manual · Voice Mode 13 for 22
Hardware and firmware version check
This command is used to check the hardware and firmware version of the MEP2L. It's a query-
only command. It answers by synthesized voice and provides four digits hhss, being hh the
hardware version and ss the firmware version. It is useful to know what features are supported
depending on the version.
Auxiliary output
The MEP2L has an optocoupled auxiliary output that allows remote control of external devices
connected to this output. It has several operating modes, which are set according to the
setting of parameter n:
Telephone line signalling (SLT)
Parameter 11 manages the use or non-use of line signalling by the MEP2L for dial-up and hang-
up tasks. By default, the MEP2L has this option enabled, so it waits for a dial tone before
dialling, and hangs up once it receives a busy tone.
Parameter 11 should be set to 0 when the MEP2L is not able to recognize certain dial tones
that are mainly used in private branch exchanges. Incoming call hanging up will be done by
timeout, unless the remote caller sends a force hang up sequence by *0#.
Usually it will not be necessary to set this parameter to 0.
COMMAND
ACTION
REMARKS
*88*
Check hard and FW version
hhss: hh see hard, ss see FW
COMMAND
ACTION
REMARKS
*28*
Consultation of programmed value
*28#n
Sets AUX output operation mode
n: 0-4 default: 0
n
ACTION
REMARKS
0
AUX output is disabled
Default value.
1
Activated if no power is available
2
Emits 1 second pulse
Use command *28#2
3
Activates when low battery or invalid test is
detected
What is it?
4
Activated while PUSHBUTTONS are ACTIVATED
Only while pressing
COMMAND
ACTION
REMARKS
*11*
Consultation of programmed value
Answer: 0 or 1
*11#n
Sets operation mode based on line signalling
or not
n: 0.1 default: 1
0: ignores SLT
1: if you use SLT
