EMERGENCY TELEPHONE FOR LIFTS
Rev. M2.4 © Merak. All rights reserved
Command Manual · Voice Mode 4 for 22
CONNECTIONS
1) Connect jumper JP1 in the connected battery position
2) Connect the telephone line to the J5 connector
3) Connect the power supply to connector J1 (10 to 30 Vdc)
4) Check that a locution "Booth 1" is heard and the LEDs perform a sequence
LOCAL PROGRAMMING VIA KEYBOARD
Entering and exiting programming mode
Enter programming mode by pressing and holding the * key until you hear a triple "beep"
sound (approx. 3 seconds)
To exit programming mode, press and hold the * key again and wait for the triple beep. If the
unit is left in programming mode, it automatically exits after two minutes without pressing any
key.
When you exit the programming mode, the valid commands you have entered are stored.
During a parameter programming session, a password will be requested, once correctly
entered it will not be requested again during the programming session. The default password
is "0000.
KEYBOARD COMMAND SYNTAX
The phone's configuration parameters can be programmed and/or consulted. The phone will
always respond via synthesised voice messages. These same commands can also be invoked by
a remote call using the keypad of the calling telephone terminal.
In the case of a query, the commands begin and end with *. For example, consulting the first
alarm number would be *02*.
The programming commands have a syntax like *NN#.... Depending on which command it is, it
ends with # or with # value
Certain parameters require a password to be consulted or programmed. Once the password
has been correctly entered, it will be valid during the programming session and will not be
requested again during the session.
Example of operating language query with parameter 81:
