Mercury 150 User Manual

FEATURES AND CONTROLS
24
Remote Control Features
Your boat may be equipped with one of the Mercury Precision or Quicksilver remote controls shown. If
not, consult your dealer for a description of the functions and operations of the remote control.
ee
aa
dd
dd
ee
ff
gg
aa
bb
ff
cc
gg
hh
bb
cc
aa
ff
ii
cc
ii
ob00329
a - Control handle - forward, neutral,
reverse.
b - Neutral release lever
c - Trim/tilt switch (if equipped). - Refer to
Features & Controls - Power Trim and
Tilt.
d - Lanyard stop switch - Refer to General
Information - Lanyard Stop Switch.
e - Lanyard - Refer to General Information
- Lanyard Stop Switch.
f - Throttle friction adjustment - Console
controls require cover removal for
adjustment.
g - Ignition key switch - "OFF," "ON,"
START."
h - Fast idle lever - Refer to Operation -
Starting the Engine.
i - Throttle only button - Refer to Operation
- Starting the Engine.
Warning System - Models with Electronic Fuel Injection (EFI)
The outboard warning system incorporates a warning horn inside the boat. Remote control models will
have the warning horn located inside the remote control or connected to the ignition key switch. Tiller
handle models will have the warning horn located in the ignition key panel.
a
b
ob00662
a - Horn inside remote control b - Horn connected to ignition key switch
WARNING HORN SIGNALS
When the key switch is turned to the "ON" position, the horn will turn on for a moment as a test to show
the horn is working.

Mercury 150 Specifications

General

Fuel Induction System	Electronic Fuel Injection (EFI)
Horsepower	150 hp
Steering	Hydraulic
Shaft Length	20" / 25"
Starting	Electric
Weight	455 lbs (20"), 462 lbs (25")
