OUTBOARD INSTALLATION

Electrical, Hoses, and Control Cables

FRONT CLAMP DISASSEMBLY

Remove screws and open the front clamp assembly.

7644

a - Screw (2) b - Front clamp

REMOTE WIRING HARNESS

Route the remote 14 pin boat harness through the front clamp. Connect remote harness to the 14 pin

connector on the engine harness.

11033

a - 14 pin connector b - Remote 14 pin boat harness
