1. Verify the throttle actuator timing mark is aligned with the timing mark on
the bracket. Adjust the throttle link if necessary to achieve proper
alignment.
a - Throttle against stop
b - Throttle link
c - Timing marks aligned
2. Locate the center point of the slack or lost motion that exists in the throttle
cable as follows:
a. Move the remote control handle from neutral into forward and advance
the handle to full speed position. Slowly return the handle back to
neutral. Place a mark (a) on the cable next to the end guide.
b. Move the remote control handle from neutral into reverse and advance
the handle to full speed position. Slowly return the handle back to
neutral. Place a mark (b) on the cable next to the end guide.
