Mercury 20 EFI FourStroke User Manual

c. Make a center mark (c), midway between marks (a and b). Align the
end guide with this center mark when installing the cable onto the
engine.
6098
b
c
a
3. Attach the throttle cable end guide to the throttle lever with a washer and
bow‑tie retainer.
4. Adjust the cable barrel so the installed throttle cable will maintain
alignment.
5. Position the throttle cable into the barrel receptacle.
a - Bow‑tie retainer
b - Flat washer
c - Throttle cable
d - Cable barrel
a
b
c
d
63129
ENGINE INSTALLATION
eng 119
