Clamp Bracket Components (Manual Tilt)
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Starboard clamp bracket
2 1 Port clamp bracket
3 1 Tilt tube
4 2 Cap
5 2 Screw 6.0 53.1 –
6 2 Anode
7 2 Nut (M6) 6.0 53.1 –
8 4 Washer
9 2 Thumb screw assembly
10 1 Spacer
11 1 Carrying handle
12 1 Locknut 24.0 – 17.7
13 1 Tilt pin assembly
14 1 Spring
15 1 Swivel bracket
16 2 Bushing
17 2 E‑clip
18 1 Reverse lock shaft
19 1 Ground wire (swivel bracket to lower mount bracket)
20 3 Grease fitting
21 2 Pin
22 2 Reverse lock spring
23 1 Reverse lock
24 1 Reverse lock arm
25 1 Reverse lock spring
26 1 Reverse lock link
27 1 Reverse lock rod
28 1 Split pin
29 2 Screw (M8 x 18) 13 115 –
30 1 Set plate
31 1 Spring pin
32 1 Tilt stopper
33 1 Bushing
34 1 Guide
35 1 Friction spring
36 1 Pin
37 1 Reverse lock lever spring
38 1 Bushing
39 1 Washer
40 1 Shoulder screw 13 115 –
41 1 Reverse lock lever grip
42 1 Stopper
43 1 Reverse lock lever
44 1 Washer
45 1 Washer
46 1 Copilot assembly
Clamp/Swivel Bracket and Driveshaft Housing
90-8M0125265 eng NOVEMBER 2017 © 2018 Mercury Marine Page 5A-7
