Driveshaft Housing Components
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Driveshaft housing assembly
2 1 Oil seal
3 1 Drain screw 24.0 – 17.7
4 1 Washer
5 2 Dowel pin
6 2 Dowel pin
7 2 Dowel pin (driveshaft extension)
8 1 Water tube
9 1 Upper water tube seal
10 1 Lock plate
11 1 Guide
12 1 Screw 6.0 53.1 –
13 1 Ground wire (driveshaft housing to lower mount bracket)
14 1 Screw 6.0 53.1 –
15 1 Flushing connector cap
16 1 Seal ring
17 1 Idle exhaust port cover
18 1 Idle exhaust cover plate
19 3 Screw 4.0 35.4 –
20 1 Idle exhaust port gasket
21 6 Screw (M6 x 16) 6.0 53.1 –
22 2 Water hose fitting
23 1 Screw 6.0 53.1 –
24 1 Rubber seal
25 1 Extension housing (driveshaft extension)
26 4 Screws (driveshaft extension) 24.0 – 17.7
27 1 Driveshaft bushing (driveshaft extension)
28 1 Stopper (driveshaft extension)
29 2 Screw (M6 x 12) (driveshaft extension) 6.0 53.1 –
Clamp/Swivel Bracket and Driveshaft Housing
90-8M0125265 eng NOVEMBER 2017 © 2018 Mercury Marine Page 5A-13
