Mercury 20 EFI FourStroke

Power Tilt Components
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Cap assembly
2 1 O‑ring
3 1 Manual release valve assembly
4 1 O‑ring
5 1 O‑ring
6 1 C‑ring
7 1 Seal
8 1 Down orifice assembly
9 1 O‑ring
10 2 O‑ring
11 1 Pump
12 1 Up relief valve assembly
13 1 O‑ring
14 2 Bolt (M5 x 20) 5.2 46.0 –
15 1 Bolt (M5 x 25) 5.2 46.0 –
16 1 Filter
17 1 Coupling
18 1 O‑ring
19 1 Motor bracket assembly
20 1 Oil seal
21 1 O‑ring
22 1 Cable tie
23 1 Screw 0.6 5.3 –
24 1 Armature assembly
25 1 Housing
26 2 Screw 5.2 46.0 –
27 2 Screw (M5) 5.2 46.0 –
Power Tilt
