Mercury 20 EFI FourStroke

Remote Control Components
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 1 Drag link assembly
2 1 Spacer
3 1 Screw
4 1 Nylon insert locknut
Tighten until it seats, then back off 1/4
turn
5 3 Washer
6 1 Seal ring
7 1 Nylon insert locknut 27.0 – 19.9
8 1 Steering hook plate
9 2 Washer
10 2 Screw 26.0 – 19.2
11 1 Throttle and shift bracket
12 3 Screw 6.0 53.1 –
13 2 Cable joint
14 2 Washer
15 2 Washer
16 2 Retaining clip
17 1 Shift arm
18 1 Collar
19 2 Washer
20 1 Washer
21 1 Screw 6.0 53.1 –
22 1 Shift lever rod
23 2 Retaining clip
24 1 Throttle arm
25 1 Throttle opener
26 1 Collar
27 1 Screw 6.0 53.1 –
28 2 Ball joint connector
29 2 Jam nut 3.0 26.6 –
30 1 Throttle link rod
31 1 Screw 6.0 53.1 –
32 1 Short detent spring
33 2 Detent spring
34 4 Screw 6.0 53.1 –
35 1 Starboard horizontal shift shaft bracket
36 1 Port horizontal shift shaft bracket
37 1 Horizontal shift shaft
38 1 Vertical shift shaft
39 1 Shift shaft coupler 4.0 35.4 –
40 1 Jam nut 4.0 35.4 –
41 1 Grommet
Throttle and Shift Linkage
