Starter Motor and Solenoid Electrical Components
Ref. No. Qty. Description
Torque
Nm lb‑in. lb‑ft
1 2 Screw (M8 x 25) 13 115 –
2 1 Starter solenoid
3 1 Screw 6.0 53.1 –
4 1 Starter cable
5 2 Screw 6.0 53.1 –
6 1 Red terminal boot
7 1 Red terminal boot
8 1 Battery cable assembly
9 1 Protective sleeve
10 2 Screw 6.0 53.1 –
11 1 Starter motor bracket
12 1 Rubber mount
13 1 Red terminal boot
14 1 Protective sleeve
15 1 Screw 6.0 53.1 –
16 1 Starter motor
– 1 Neutral switch (tiller)
– 1 Start switch (tiller)
