Mercury 200 User Manual

OUTBOARD INSTALLATION
103
3. Mark the center on the shift cable midway between the forward
and reverse marks.
4361
a
a - Center mark
4. Align the cable end guide against this center mark when
installing the cable to the engine.
5. Position the remote control and outboard into neutral position.
6. Slide the anchor pin forward until resistance is felt, then slide
the anchor pin toward the rear until resistance is felt.
7. Center the anchor pin between these resistance points.
a
28746
a - Anchor pin
Adjusting the Shift Cable
1. Align the shift cable end guide with the center mark as
instructed in Locating the Center Point of the Shift Cable.
4362
a
a - Center mark

Mercury 200 Specifications

General

Fuel Induction System	Electronic Fuel Injection (EFI)
Displacement	3.0L (181 cubic inches)
Horsepower	200 HP
Alternator Output	60-amp
Shaft Length	20", 25"
Steering	Hydraulic
Weight	505 lbs (20" shaft), 515 lbs (25" shaft)
Starting System	Electric
