Mercury 4 SERIES

CYLINDER BLOCK AND CRANKCASE
90-857138R1 MAY 2000 Page 4B–11
Oil Pan
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
1 1 SCREW (M5 x 16 mm) 31 3.5
2 1 STOPPER
3 1 TUBING
4 2 SEAL
5 2 SCREW (M5 x 16 mm) 31 3.5
6 2 WASHER
7 1 STRAINER HOUSING
8 1 STRAINER
9 1 CUP
10 2 DOWEL PIN
11 1 LEAD WIRE
12 1 OIL PRESSURE SWITCH
13 1 GROMMET
14 3 BOLT (M6 x 20 mm) 70 8
15 1 EXHAUST PLATE
16 1 GASKET
17 1 OIL PAN
18 3 BOLT (M6 x 40 mm) 80 9
19 1 ROTOR-OUTER
20 1 PIN
21 1 ROTOR-INNER
22 1 O RING
23 1 COVER
24 2 BOLT (M6 x 16 mm) 70 8
25 2 BOLT (M6 x 20 mm) 70 8
26 1 HOUSING
27 2 OIL SEAL
28 1 SPACER
29 1 GASKET
30 1 OIL SEAL
31 1 DRAIN BOLT
32 1 WASHER
33 6 BOLT (M8 x 40 mm) 221 18.5 25
34 1 GASKET
35 1 CONTROL PLUNGER
36 1 SPRING
37 1 O RING
38 1 SEAT
39 1 COVER
40 1 BOLT (M6 x 16 mm) 70 8
– 1 GASKET SET
