OUTBOARD MOTOR INSTALLATION

90-857138R1 MAY 2000 Page 1D-3

Installing Outboard

1. Measure the transom height of your boat. The boat bottom should be aligned or be within

1 in. (25 mm) above the anti-ventilation plate of the outboard.

1-2 in.

(25 - 50 mm)

a-Anti-Ventilation Plate

2. Place outboard on center line of transom.

3. Tighten transom clamp handles.
