Mercury 4 SERIES

MANUAL STARTER
90-857138R1 MAY 2000 Page 8-3
Recoil Starter
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in. lb-ft Nm
– 1 RECOIL STARTER ASSEMBLY
1 1 STARTER HOUSING
2 1 SPRING SET
3 1 REEL
4 2 RETURN SPRING
5 1 FRICTION SPRING
6 2 RATCHET
7 1 FRICTION PLATE
8 1 BOLT 70 8
9 1 SEAL PLATE
10 1 STARTER ROPE
11 1 STARTER HANDLE
12 1 ROPE ANCHOR
13 1 STARTER PULLEY
14 3 BOLT 70 8
15 2 ROD SNAP
16 1 STARTER LOCK ROD
17 1 STARTER LOCK CAM
18 1 SCREW Drive Tight
19 1 COLLAR
20 2 WASHER
21 1 SPRING
22 1 STARTER LOCK
23 1 SCREW Drive Tight
24 1 SPRING
25 1 COLLAR
26 3 BOLT 70 8
27 3 LOCKWASHER
28 1 CLAMP
29 1 LOCKWASHER
