FUEL PUMP & INTREGAL FUEL TANK
Page 3A-8 90-857138R1 MAY 2000
5. Install the pump body to the pump cover with four screws.
b
c
a
d
a-Pump Cover
b-Gasket
c-Pump Body
d-Screws (4)
