Mercury 45 User Manual

INSTALLATION
30
MODELS WITH TRANSOM BRACKET CLAMP SCREWS
The outboard must be secured to the transom one of two ways:
EITHER with clamp screws and the two mounting bolts and
locknuts provided, OR with clamp screws and optional Quicksilver
or Mercury Precision Parts Outboard Mounting Kit. Tighten
retainer screws into the lower mounting holes when using outboard
mounting kit.
a
b
a
d
c
27378
a - Clamp screws
b - Mounting bolt and
locknut (2)
c - Outboard Mounting Kit
(part number 812432A5)
d - Retainer screws

Mercury 45 Specifications

General

Horsepower	45 HP
Cylinders	3
Starting	Electric
Full Throttle RPM Range	5000-6000 RPM
Steering	Remote
Exhaust	Through Prop
Shaft Length	20 in
