NOTE: A quick‑reference decal which lists the type of oil to use is located on
the underside of the hood.
a - Decal
b - Oil fill cap
c - Dipstick
3. Remove the dipstick, wipe it clean, and install it fully into the dipstick tube.
4. Remove the dipstick and observe the oil level. The oil level should be
within the safe operating range.
a - Safe operating range
b - Add 3.8 Liter (4.0 US qt) of oil
c - Target oil level (1/2 to 2/3 above bottom of crosshatch)
5. If the oil level is below the ADD mark, or is not visible on the dipstick,
remove the oil fill cap and add 3.8 Liter (4.0 US qt) of the recommended
oil.
6. Allow a few minutes for the oil to drain into the sump and insert the oil
dipstick.
FUEL AND OIL
eng 25
