PANEL MOUNT ERC
Panel mount ERCs control a single engine. There are several variations, but
only one of these can be used with electric steering (ES).
Ref Control/LED Function
a
Neutral (N) LED
Illuminates when the engine is in the
neutral gear position. The light
flashes when the engine is in
throttle‑only mode.
b
Brightness (+ and –)
Increases and decreases the
brightness settings for the lights on
the ERC and Mercury helm
components.
c
THROTTLE ONLY
Allows the boat operator to increase
engine RPM without shifting into
gear. Refer to Throttle‑Only Mode.
d
QUICK STEER (if
equipped)
Decreases the number of steering
helm turns, lock‑to‑lock, for quicker
response during docking. This
feature also limits engine speed.
Refer to Quick Steer.
FEATURES AND CONTROLS
eng 29
