Ref Control/LED Function
e
ACTIVE TRIM (if
equipped)
The ACTIVE TRIM button turns the
Active Trim feature ON or OFF. Refer
to Active Trim.
Profile ▲ and ▼
Changes the selected Active Trim
profile.
Active Trim LEDs (1,
2, 3, 4, 5)
Indicates the currently selected
Active Trim profile.
NOTE: If the LED indicators are
flashing, Active Trim is in setup mode.
f
Lanyard stop switch
(emergency stop)
In conjunction with the lanyard cord,
shuts off the engine when the
operator moves away from the ERC.
g
START/STOP
ENGINE
Starts or stops the engine.
h
UP ▲ and DN ▼—
trim control
Raises and lowers the engine/drive
for best efficiency, or for conditions
such as shallow water or trailering.
Some boats are equipped with
separately‑mounted trim controls.
i Mechanical lock bar
Pressing the mechanical lock bar
allows the engine to shift. The
mechanical lock bar must always be
pressed when moving the control
handle out of the neutral position.
FEATURES AND CONTROLS
30 eng
