SINGLE-HANDLE CONSOLE ERC
Single‑handle console ERCs control a single engine. There are several
variations, but only one of these can be used with electric steering (ES).
Ref Control/LED Function
a
Neutral (N) LED
Illuminates when the engine is in the neutral gear
position. The light flashes when the engine is in
throttle‑only mode.
b
Brightness (+ and
–)
Increases and decreases the brightness settings
for the lights on the ERC and Mercury helm
components.
c
TRANSFER
Allows boat control to be transferred to a different
helm. (The LED will be ON at the active helm.)
Refer to Helm Transfer.
d
THROTTLE ONLY
Allows the boat operator to increase engine RPM
without shifting into gear. Refer to Throttle‑Only
Mode.
e
QUICK STEER (if
equipped)
Decreases the number of steering helm turns,
lock‑to‑lock, for quicker response during docking.
This feature also limits engine speed. Refer to
Quick Steer.
f
ACTIVE TRIM (if
equipped)
The ACTIVE TRIM button turns the Active Trim
feature ON or OFF. Refer to Active Trim.
Profile ▲ and ▼
Changes the selected Active Trim profile.
Active Trim LEDs
(1, 2, 3, 4, 5)
Indicates the currently selected Active Trim profile.
NOTE: If the LED indicators are flashing, Active
Trim is in setup mode.
g
START/STOP
ENGINE
Starts or stops the engine.
FEATURES AND CONTROLS
eng 31
