Premier ERCs have an integral, supplemental display, and are available for
dual, triple, or quad‑engine configurations. Refer to ERC Supplemental
Display for details.
Dual-handle, quad-engine premier ERC shown, others similar
Ref Control/LED Function
a
Neutral (N) LEDs
(one on each
handle)
Illuminate when the engine is in the neutral gear
position. The lights flash when the engine is in
throttle‑only mode.
b
Brightness (+ and –)
Increases and decreases the brightness settings
for the lights and display (if equipped) on the ERC
and Mercury helm components.
c
1 LEVER
Enables the throttle and shift functions of all
engines to be controlled by the port lever. Refer to
Single‑Lever Mode.
d
TRANSFER
Allows boat control to be transferred to a different
helm. (The LED will be ON at the active helm.)
Refer to Helm Transfer.
e
THROTTLE ONLY
Allows the boat operator to increase engine RPM
without shifting into gear. Refer to Throttle‑Only
Mode.
f
ACTIVE TRIM (if
equipped)
The ACTIVE TRIM button turns the Active Trim
feature ON or OFF. Refer to Active Trim.
Profile ▲ and ▼
Changes the selected Active Trim profile.
Active Trim LEDs
(1, 2, 3, 4, 5)
Indicates the currently selected Active Trim profile.
NOTE: If the LED indicators are flashing, Active
Trim is in setup mode.
FEATURES AND CONTROLS
eng 33
