90-855347R1 JANUARY 1999 Page 3B-7
Air Handler
REF.
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
1 1 COVER ASSEMBLY
2 2 GROMMET
3 1 AIR FILTER
4 1 COVER
5 1 RIVET
6 1 RETAINER
7 1 GROMMET
8 1 GROMMET (150)
9 1 GROMMET (135)
10 1
AIR HANDLER ASSEMBLY
(See Breakdown on Air Handler Components)
11
1 SHIM (.020 THICK)
11
1 SHIM (.010 THICK)
12 1 DECAL-Caution-Start in Gear
13 1 BRACKET
14 1 SLEEVE
15 4 SCREW (M6 x 16) 100 11.5
16 1 FUEL PUMP
17 4 CLAMP
18 1 HOSE
19 1 TUBING (18 IN.)
20 1 INSULATING SLEEVE
21 1 ELBOW
22 1 FITTING
23 1 O RING
24 1 GROMMET
25 1 ENCODER
26 1 SCREW (10-24 x 5/8 IN.) Drive Tight
27 1 WASHER
28 2 J CLAMP (Upper Stbd.)
29 1 CLAMP-(Lower)
30 12 SCREW (1/4-20 x 1-1/2 IN.) 175 15 20
31 1 TUBING (5-3/4 IN.)
32 1 CANISTER-Vent
33 3 STA STRAP
34 1 CONNECTOR
35 1 PIN
36 1 DECAL EPA LABEL (1999) (SEE NOTE)
37 1 CABLE TIE (14 IN.)
38 1 CABLE
39 1 WASHER
40 1 WASHER
NOTE: THE EPA LABEL HAS IMPORTANT INFORMATION ON EPA EMISSION REGULATIONS. REPLACE ANY
MISSING OR UNREADABLE EPA LABEL.

Mercury Optimax 150 Specifications

General

Horsepower	150 HP
Engine Type	V6
Alternator Output	60 amp / 756 watt
Starting	Electric
Steering	Remote
Displacement	2.5 L
Fuel Induction System	2-Stage Direct Fuel Injection (DFI)
Shaft Length	20", 25"
Dry Weight	431 lbs (20 in), 439 lbs (25 in)
