DIRECT FUEL INJECTION
Page 3B-12 90-855347R1 JANUARY 1999
Fuel Rails/Air Compressor Hose Routing
Mineral Oil (Purchase Locally)
54
2
3
1
4
5
7
9
10
11
16
17
18
19
20
21
22
23
24
25
26
27
28


8
9
9
9
9
9
10
12
13
14
14
14
14
14
15
20°

14

20

90°
54

6
29
29
14
30
54
A = TO TELL TALE B = TO STARBOARD FUEL RAIL C = TO FUEL COOLER D = TO TOP OF AIR HANDLER
E = QTY. OF ONE (1) ON EACH SIDE OF COMPRESSOR FLANGE G = TO VAPOR SEPARATOR

Mercury Optimax 150 Specifications

General

Horsepower	150 HP
Engine Type	V6
Alternator Output	60 amp / 756 watt
Starting	Electric
Steering	Remote
Displacement	2.5 L
Fuel Induction System	2-Stage Direct Fuel Injection (DFI)
Shaft Length	20", 25"
Dry Weight	431 lbs (20 in), 439 lbs (25 in)
