Mercury Optimax 150 User Manual

DIRECT FUEL INJECTION
Page 3B-6 90-855347R1 JANUARY 1999
Air Handler
A = OIL LINE TO COMPRESSOR
B = TO FITTING IN FLYWHEEL COVER
C = PRESS INTO TUBING
Loctite Superbonder 454 GEL
96
10
25
12
2
30
3
26
8
1
2
30
5
6
A
35
96
4
29
27
36
28
9
13
16
19
20
21
22
23
17
17
17
18
24
7
33
33
31
32
B
C
34
37
15
38
39
40
11
14

Mercury Optimax 150 Specifications

General

Horsepower	150 HP
Engine Type	V6
Alternator Output	60 amp / 756 watt
Starting	Electric
Steering	Remote
Displacement	2.5 L
Fuel Induction System	2-Stage Direct Fuel Injection (DFI)
Shaft Length	20", 25"
Dry Weight	431 lbs (20 in), 439 lbs (25 in)
