DIRECT FUEL INJECTION
90-855347R1 JANUARY 1999 Page 3B-17
Air Compressor Components
REF.
TORQUE
REF
.
NO.
DESCRIPTION lb-in lb-ft Nm.
1 AIR COMPRESSOR
2 END CAP
3 RETAINING RING
4 SCREW (M6 x 20) 100 11.5
5 O RING
6 O RING
7 CONNECTING ROD
8 PISTON ASSEMBLY
9 LOCK RING
10 REED PLATE ASSEMBLY
11 O RING
12 O RING
13 SEAL
14 COMPRESSOR HEAD
15 FITTING-Straight
16 SCREW (M8 x 35) 240 20 27
17 ELBOW
18 ELBOW
19 FITTING-Straight
20 TEMPERATURE SENSOR
21 RETAINER
22 SCREW (M8 x 12) 240 20 27
23 O RING
24 FITTING
25 PIPE PLUG
26 DECAL-Important
27 GROMMET
– O RING KIT
