Mercury Optimax 150 User Manual

DIRECT FUEL INJECTION
Page 3B-48 90-855347R1 JANUARY 1999
6. Disconnect water outlet hose (tell-tale).
56149
a
b
a
b
a-Air Pressure Outlet Hose
b-Water outlet Hose (tell-tale)
7. Disconnect air compressor oil inlet hose.
8. Disconnect water inlet hose.
9. Disconnect excess oil return hose.
56147
a
b
c
a
b
c
a-Air Compressor Oil Inlet Hose
b-Water Inlet Hose
c-Excess Oil Return Hose
10. Remove 4 bolts securing air compressor to outboard and remove compressor.

Mercury Optimax 150 Specifications

General

Horsepower	150 HP
Engine Type	V6
Alternator Output	60 amp / 756 watt
Starting	Electric
Steering	Remote
Displacement	2.5 L
Fuel Induction System	2-Stage Direct Fuel Injection (DFI)
Shaft Length	20", 25"
Dry Weight	431 lbs (20 in), 439 lbs (25 in)
